FS-B Bulk Parts Elevator

Model FS-B
Automatic Bulk Parts Elevator Hopper

Bulk Parts Elevator has been designed for the feeding of Caps and other similar parts.

Standard Features:

  • All stainless steel chassis, hood and guards.
  • Heavy duty construction--low cost.
  • No change parts required.
  • Electronic variable speed drive with dial control.
  • Large five (5) cubic foot capacity stainless steel hopper.
  • Adjustable stainless steel leveling screws with floor pads.
  • FDA and USDA approved belting with molded cleats.
  • NEMA 12 electrics and control box. No air required.
  • Two-year guarantee--the longest in the industry.
  • Stationary operation or easily moved from one position to another with mobile base and heavy duty swivel casters.
  • Low maintenance cost with no skilled personnel required.
  • Gentle product handling.
  • Clear Polycarbonate dust cover over inclined belt.
  • Wide range of height adjustments.
  • Compact design for restricted ceiling heights.
  • Easily integrated into KAPS-ALL machines or can be
    used independently.

Available options:

  • Hazardous location controls and other special electrical requirements.
  • Eight (8) and twenty (20) cubic foot hoppers to replace standard five (5) cubic foot hoppers.
  • Hinged hopper covers.
  • Stainless steel mobile base.



  • Special discharge heights.
  • Clean-out door on hopper.

Ideal For:

Ideal for the feeding of Caps, Plugs, Dip Tubes, Aerosol Valves, Pumps, Bottles, Jars, and other similar parts



110v AC, 1Phase, 50/60 hertz


220v AC, 1 phase, 50/60 hertz


No air necessary



- Crated Machine Weight: 350lbs

- Shipping Measurements:  Crated 8’x4’x4’
